Imperial® IR-4-G24-C-XB 48(w) inch, (4)Open Burner(s) with 24(w) inch Griddle and (1)Convection Oven(s), Natural Gas, 198k Total BTU/Hr, ETL Listed

Imperial® IR-4-G24-C-XB 48(w) inch, (4)Open Burner(s) with 24(w) inch Griddle and (1)Convection Oven(s), Natural Gas, 198k Total BTU/Hr, ETL Listed
Free Shipping
Imperial® IR-4-G24-C-XB 48(w) inch, (4)Open Burner(s) with 24(w) inch Griddle and (1)Convection Oven(s), Natural Gas, 198k Total BTU/Hr, ETL Listed

Imperial® IR-4-G24-C-XB 48(w) inch, (4)Open Burner(s) with 24(w) inch Griddle and (1)Convection Oven(s), Natural Gas, 198k Total BTU/Hr, ETL Listed

(4)OPEN BURNER(S) RESTAURANT GAS RANGE WITH GRIDDLE Model No: IR-4-G12-C

From the Manufacturer
(shown with optional casters)

OPEN BURNERS

  • PyroCentric™ 32,000 BTU (9 KW) anti-clogging burner with a 7,000 BTU/hr. (2 KW) low simmer feature. Two rings of flame for even heating.
  • Burners are anti-clogging and lift-off and separate for easy cleaning. No gaskets or screws.
  • Cast iron PyroCentric burners are standard on all IR Series Ranges.
  • One standing pilot per burner for instant ignition.

CONVECTION OVENS

  • 30,000 BTU/hr. (9 KW) convection oven with 1/2 hp blower motor cooks products quickly and evenly with less shrinkage.
  • Convection oven interior dimensions 26-1/2” w x 22-1/2” d x 14” h (673 x 572 x 356 mm).
  • Three position switch for cooking or cool down. Fan shuts off automatically when door is open.
  • Porcelainized sides, rear, deck and door lining for easy cleaning. Heavy duty door hinge.
  • Three chrome oven racks are included.
  • Electronic ignition system with electronic timer countdown.

GRIDDLE

  • Highly polished 3/4” (19 mm) steel plate. 21” (533 mm) plate depth.
  • Burners have 20,000 (6 KW) BTU/hr. output with a heat deflector every 12” (305) for even heating.
  • 3” (76 mm) wide grease trough and removable grease can for easy cleaning.
  • Large griddle grease can and full width broiler drip tray are removable for easy cleaning.

GRATES

  • Front grates measure 12” x 12” (305 x 279 mm). Back grates are 12” x 13” (305 x 330 mm).
  • Back grates are sized for positioning large stock pots directly over burner and feature a hot air dam.
  • Grates are cast iron for a long service life.
  • All stainless steel upper burner box, top grate supports front and rear.
  • Stainless steel front, sides, backguard, shelf, landing ledge and kick plate
  • Welded and polished stainless steel seams
  • Large 3.5” (127 mm) stainless steel landing ledge
  • Control knobs are durable cast aluminum.
  • Full width, removable crumb tray under open burners for easy cleaning
  • 6” (152 mm) heavy duty legs with adjustable feet
  • One year parts and labor warranty

EXTERIOR

  • Reinforcement channels for mounting cheese melter and salamander
  • 6” and 11” (152 and 279 mm) stainless steel backguards. Stubback available
  • 10” (254 mm) stainless steel wok ring
  • Saute burner head, interchangeable
  • Wok burner head, interchangeable

OPTIONS AND ACCESSORIES

  • For use only on non-combustible floors. Legs or casters are required for non-combustible floors; or 2” (51 mm) overhang is required when curb mounted. Provide 0” clearance from non-combustible surfaces and 8” (203 mm) from combustible surfaces.
  • Extra oven racks
  • Thermostatic griddle control
  • Grooved griddle plate
  • Griddle safety valve
  • Gas shut off valve 3/4” (19 mm)
  • Quick disconnect and flexible gas hose
  • 6” (152 mm) casters
  • For use only on non-combustible floors.
  • Legs or casters are required for non-combustible floors; or 2” (51 mm) overhang is required when curb mounted. Provide 0” clearance from non-combustible surfaces and 8” (203 mm) from combustible surfaces.

 WARNING: Attention California Residents - Prop 65 Warning www.P65Warnings.ca.gov


Number of Sections and Doors
Casters : Legs
Certification and Origin
Listed : NSF
Origin : USA
Dimensions
Dimension (l"xw"xh") : 48 x 31-1/2 x 56-1/2
Gas
Gas Types : Natural
Capacity
Total BTU / Hr : 198k
Usage
Usage Types: Burner Ranges
Burners
Number of Burner(s) : 4
Oven
Oven Type : Convection
Griddle
Griddle Plate Depth (inch): 24
Thumb File information
Warranty.pdf 98.65KB 15
External Links
Thumb Link Name
Technical Specs
User Manual

Write a review

$16,855.85
  • Stock: 1
  • Model: IR-4-G24-C-XB
  • SKU: 327-IR-4-G24-C-XB
  • MPN: IR-4-G24-C-XB
